Intelligent Switch Monitor Module VdS

Name: Intelligent Switch Monitor Module VdS
Brand: Discovery
SKU: SA4710-100APO

SA4710-100APO

The Intelligent Switch Monitor Module is used to monitor one or more single pole, volt free contacts connected on a single pair of cables and report status to fire control panel.

VdS2543 and EN54-13 Certified
Priority and non-priority settings
Switchable time delay on input for use when monitoring flow switches
Ergonomic design for ease of wiring and faster installation
Suitable for semi flush or surface mounting
XP95, Discovery and CoreProtocol compatible

Technical specification

General	Warranty 10 year
Mechanical	Colour White Weight 239g Product length 60mm Product width 150mm Product depth 90mm Product length 2.36in Product width 5.91in Product depth 3.54in
Conformance	Standards EN 54-17 EN 54-18 Approvals FG LPCB SBSC BOSEC VdS CPR
Electrical	Protocol voltage (min) 5V Protocol voltage (max) 13V Protocol voltage 5 to 13V peak to peak Quiescent current 500μA Quiescent current tested at 24V dc Supply voltage (max) 35V dc Supply voltage (min) 17V dc Supply voltage (Vmin-Vmax) 17 to 35V dc
Environmental	Humidity 95% to 0% (no condensation or icing) Humidity Note no condensation or icing Humidity (max) 0% RH Humidity (min) 95% RH Operating temperature -40 to 70°C Operating temperature (max) 70°C Operating temperature (min) -40°C IP rating Value IP52 Operating temperature -40 to 158°F Operating temperature (max) 158°F Operating temperature (min) -40°F
